ECS Elitegroup KV2 Extreme [85/111] Form factor

Italiano

• 1 x connettore di alimentazione 20-pin ATX e connettore 4-pin

da 12 V

• 1 x connettore oppy - supporta 360K ~ 2.88M Byte, 3 Mode

FDDs o LS120

• 3 x connettori IDE

• 4 x connettori seriali ATA

• 2 x supporti header USB 2.0 con 4 porte USB supplementari

• 2 x headers 1394a

• 1 x EZ-Watcher header (opzionale)

• 1 x SMBus header

• 1 x interruttore del pannello frontale /LED header

• 1 x pannello frontale header audio

• CD in/AUX in header

• Connettori CPUFAN/NB_FAN/CASFAN

• Dimensione -ATX

• 305mm x 244mm

Form Factor

I/O interno
