ECS Elitegroup KV2 Extreme [81/111] E s interne

Français

• 1 x Connecteur d’alimentation ATX 20 broches & Connecteur 12

V 4 broches

• 1 x connecteur de lecteur de disquette- prenant en charge 360K

~ 2,88M octets, 3 Lecteurs de disquettes Modes ou LS120

• 3 x connecteurs IDE

• 4 x connecteurs ATA Série

• 2 x embases USB 2.0 supportant 4 ports USB supplémentaires

• 2 x embases 1394a

• 1 x embase EZ-Watcher (optionnelle)

• 1 x embase SMBus

• 1 x embase de commutateur/LED de panneau avant

• 1 x embase audio de panneau avant

• Embase entrée CD/entrée AUX

• Connecteurs CPUFAN/NB_FAN/CASFAN

• Taille ATX

• 305mm x 244mm

Facteur de

Forme

E/S interne
