Инструкция по эксплуатации Страница: 11

Asus rog rampage v edition 10 [11/130] Rampage v edition 10 specifications summary

ROG Exclusive Features

Extreme Engine Digi+

- MicroFine Alloy Choke

- IR3555 PoweIRstage

- 10K Black Metallic Capacitors

OC Zone

- ReTry button

- Safe Boot button

- LN2 Mode header

- Slow Mode switch

- Start button

- Reset button

- ProbeIt

- PCIe x16 lane switch

- DRAM channel switches

ROG RAMCache

ROG RAMDisk

AURA

KeyBot II

- One-click overclocking

- X.M.P.

- DirectKey

- CLr CMOS

- Power On

UEFI BIOS features:

- Extreme Tweaker

- Tweakers’ Paradise

- ROG SSD Secure Erase

- GPU.DIMM Post

- O.C. Prole

- Graphics Card Information Preview

(continued on the next page)

RAMPAGE V EDITION 10 specifications summary
