Asus rog rampage v edition 10 [80/130] Chapter 3

3-4

Chapter 3: BIOS Setup

Chapter 3

3.2.2 Advanced Mode

The Advanced Mode provides advanced options for experienced end-users to congure

the BIOS settings. The gure below shows an example of the Advanced Mode. Refer to the

following sections for the detailed congurations.

To switch from EZ Mode to Advanced Mode, click Advanced Mode(F7) or press the <F7>

hotkey.

Menu items

General helpSub-menu item

Menu bar

Last modified settings

Go back to

EZ Mode

Displays the CPU temperature,

CPU, and memory voltage output

Language

Hot Keys

Qfan Control(F6)

MyFavorite(F3)

Quick Note (F9)

EZ Tuning Wizard(F11)

Scroll bar

Pop-up Menu

Configuration fields

Search on

the FAQ
