Asus rog rampage v edition 10 [43/130] Internal connectors
![Asus rog rampage v edition 10 [43/130] Internal connectors](/views2/1214197/page43/bg2b.png)
ASUS RAMPAGE V EDITION 10
1-25
Chapter 1
1.1.9 Internal connectors
1. Intel
®
X99 Serial ATA 6 Gb/s connectors (7-pin SATA6G_1-10)
TheseconnectorsconnecttoSerialATA6Gb/sharddiskdrivesviaSerialATA6Gb/s
signal cables.
IfyouinstalledSerialATAharddiskdrives,youcancreateaRAID0,1,5,and10
congurationwiththeIntel
®
RapidStorageTechnologythroughtheonboardIntel
®
X99
chipset.
• Theseconnectorsaresetto[AHCI Mode]bydefault.IfyouintendtocreateaSerial
ATARAIDarrayusingtheseconnectors,settheSATAModeitemintheBIOSto
[RAID Mode]. Refer to the PCH Storage Configuration section for details.
• BeforecreatingaRAIDarray,referto4.1 RAID configurations section or the manual
bundledinthemotherboardsupportUSBdrive.
