1-26
Chapter 1: Product Introduction
Chapter 1
2. ROG Extension connector (18-1 pin ROG_EXT)
ThisconnectorisfortheOCPanelI/II,FrontBase,andotherROGdevices.
• TheFrontBaseispurchasedseparately.
• Visitwww.asus.comformoreinformationabouttheOCPanelandFrontBase.
3. Thermal sensor cable connector (2-pin T_SENSOR1)
Thisconnectorisforthethermistorcablethatmonitorsthetemperatureofthedevices
andthecriticalcomponentsinsidethemotherboard.Connectthethermistorcable
andplacethesensoronthedeviceorthemotherboard’scomponenttodetectits
temperature.
TomonitorthetemperatureattheBIOS,gotoBIOS>Monitor>Temperature Monitor.
