ASUS RAMPAGE V EDITION 10
2-15
Chapter 2
USB BIOS Flashback port
2.2 BIOS update utility
USB BIOS Flashback
USBBIOSFlashbackallowsyoutoeasilyupdatetheBIOSwithoutenteringtheexisting
BIOSoroperatingsystem.SimplyinsertaUSBstoragedevicetotheUSBport,pressthe
USBBIOSFlashbackbuttonforthreeseconds,andtheBIOSisupdatedautomatically.
To use USB BIOS Flashback:
1. DownloadthelatestBIOSlefromtheASUSwebsite.
2. ExtractandrenametheBIOSimageletoR5E10.CAP.
3. Copy R5E10.CAPtotherootdirectoryofyourUSBstoragedevice.
4. TurnoffthesystemandconnecttheUSBstoragedevicetotheUSBBIOSFlashback
port.
5. PresstheUSBBIOSFlashbackbuttonfor3secondsuntiltheBIOS_LED1orBIOS_
LED2ashes.
AashinglightindicatesthattheBIOSFlashbackfunctionisenabled.Thelightgoesout
whentheprocessofupdatingtheBIOSiscomplete.
USB BIOS Flashback button KeyBot II port
• FormoreBIOSupdateutilitiesinBIOSsetup,refertothesectionUpdatingBIOSin
Chapter 3.
• ConnectyourUSBkeyboardontheKeyBotIIportifyouwanttousetheKeyBot
feature.
UpdatingBIOSmayhaverisks.IftheBIOSprogramisdamagedduringtheprocessand
resultstothesystem’sfailuretobootup,pleasecontactyourlocalASUSServiceCenter.
