13
Reference
A complete list of accessories and spares can be found at: http://www.intel.com/p/en_US/support/ (post-production only).
Air Flow
1
2
3
Fixed System Fans
System Fan Connection
DIMM_A2
DIMM_A1
DIMM_B2
DIMM_B1
FAN 1
FAN 4
FAN 2 FAN 3
