4
General Installation Process
C
AIRFLOW
Chassis Front
2
3
1
4
A
B
TIM
D
CAUTION:
Do not
over-tighten
fasteners.
E
Note: Heatsink styles may vary.
Remove the protective film on the TIM if present.
D
CAUTION: The heatsink has thermal interface
material (TIM) on the underside of it. Use caution so
that you do not damage the thermal interface material.
Use gloves to avoid sharp edges.
E
C
A
B
Align heatsink fins to the front and back of
the chassis for correct airflow.
Airflow goes from front-to-back of chassis.
Each heatsink has four captive fasteners and
should be tightened in a diagonal manner using
the following procedure:
Using a #2 Phillips* screwdriver,
start with screw 1 and engage screw
threads by giving it two rotations
and stop. (Do not fully tighten.)
Proceed to screw 2 and engage screw
threads by giving it two rotations and
stop. Similarly, engage screws 3 and 4.
Repeat steps C and D by giving each
screw two rotations each time until
each screw is lightly tightened up to
a maximum of 8 inch-lbs torque.
6
Install Processor Heatsink
7
Install Memory Modules
DDR3L DIMM Memory Identification:
Other
Memory
DDR3
CAUTION: Observe normal ESD (ElectroStatic
Discharge) procedures to avoid possible damage to
system components.
DIMM notch and socket bump must align as shown below.
This server board supports up to 6 DDR3L 1333/1600
ECC UDIMM. Non-ECC memory is NOT supported by
this server board.
Note: For additional memory configurations, see the Service Guide on the
Intel
®
Server Deployment & Management DVD that accompanied
your Intel
®
Server System, or go to:
http://www.intel.com/p/en_US/support/ (post-production)
Memory sizing and configuration is supported only for qualified DIMMs approved by
Intel
®
. For a list of supported memory, go to:
http://serverconfigurator.intel.com/sct_app.aspx (post-production)
For the best performance, a minimum of three DIMMs per CPU is recommended,
populated in the blue slot of each memory channel.
Install Memory Modules ...continued
Memory Configurations and Population Order:
Intel
®
Server Board S1200V3RPM
DIMM_A2
DIMM_A1
DIMM_B2
DIMM_B1
CPU Socket
Install DIMM Memory Modules ... Continued
To Install DIMMs:
Open both DIMM socket levers.
C
A
D
E
Note location of alignment notch.
B
CAUTION: Avoid touching contacts
when handling or installing DIMMs.
A
C
D
B
E
IMPORTANT! Visually check that each latch is fully closed and correctly engaged with each DIMM edge slot.
Push down firmly on the DIMM until it snaps into place and both levers close.
Insert DIMM making sure the connector edge of the DIMM aligns correctly with the slot.
