Intel r1208rpmshor934323 [18/44] Cpu power
![Intel r1304rpssfbn [18/44] Cpu power](/views2/1219989/page18/bg12.png)
14
Reference
For system with 4 x 3.5” fixed hard drive bay:
System Cabling Diagram
Optical Drive
SAS Module
Main Power
FAN 1 FAN 2 FAN 3
PS AUX
SYS FAN_1
SYS FAN_2
CPU Power
SYS FAN_3
SATA 4
Front Panel
Front Panel USB
SATA 0
SATA 2
SATA 1
SATA 3
Intel
®
Integrated
RAID Module
BBU
3.5”
SATA
HDD
7 Pin
SATA
1x5 Pin
SATA
Pwr
3.5”
SATA
HDD
7 Pin
SATA
1x5 Pin
SATA
Pwr
3.5”
SATA
HDD
7 Pin
SATA
1x5 Pin
SATA
Pwr
3.5”
SATA
HDD
7 Pin
SATA
1x5 Pin
SATA
Pwr
350W
Power
Supply
