System Fans
Memory Slots
PCI Slots
Server Board
CPU
Air Duct
Hard Drive Bays
Front Control Panel
Power Supply
System Features and Components
* 2.5" Hard Drive Bay system as shown
1
System Overview
Intel® Server System R1000RP Family
