General Installation Process
8
Install
Hard Drives
D
C
2.5" HDD
E
2.5" Hard Drive Carrier (For system with 2.5" hard drive bay only)
Hard Drive Numbering Diagram
Drive 0 Primary
8 x 2.5" hard drive bay as shown
A
B
Remove the drive carrier by pressing the
green
latch
to unlock.
Pull out the black lever and slide the carrier out.
Remove the four screws securing the plastic drive blank
from the 2.5” HDD carrier.
Disengage the plastic drive blank from the HDD carrier.
Remove the plastic drive blank from the 2.5” HDD carrier.
C
D
Install the hard disk drive using the four screws as shown. Make Sure
that the connector end of the drive matches the backplane connector.
E
With the lever open, insert the hard disk drive assembly into the chassis,
then push in the lever to lock it into place.
F
CAUTION: If you do not
install all drives, empty drive
bays must be occupied by
carriers with plastic drive
blank provided to maintain
proper system cooling.
A
B
F
0
1
2
3
4
5
6
7
