Intel r1208rpmshor934323 [41/44] Reference
![Intel r1208rpmshor934323 [41/44] Reference](/views2/1219989/page41/bg29.png)
15
Reference
4 x 3.5" HSBP
SATA SGPIO
HDD O
HDD 1 HDD 2
HDD 3
Optical Drive
I
2
C
HSBP_I
2
C
SAS Module
Main Power
Front Panel
Front Panel USB
FAN 1 FAN 2 FAN 3
PS AUX
SATA 4
SATA 0
SATA 2
SATA 1
SATA 3
SYS FAN_1
SYS FAN_2
350W
Power
Supply
CPU Power
SYS FAN_3
Intel
®
Integrated
RAID Module
BBU
For system with 4 x 3.5” hot swap hard drive bay:
System Cabling Diagram
