22 Intel® Integrated RAID Module RMS25PB0x0 and RMS25CB0x0 Hardware User’s Guide

Table 3. SFF8087 Internal Connector with one SGPIO Connector Pin-out

Controller Connector Pin-out Backplane Connector Pin-out

Port

SFF-8087 Pin # Pin Definition Pin # Pin Definition

A1 GND 7 GND Port 0

A2 RX0+ 6 TX+

A3 RX0- 5 TX-

B1 GND 4 GND

B2 TX0+ 2 RX+

B3 TX0- 3 RX-

B4 GND 1 GND

A4 GND 7 GND Port 1

A5 RX1+ 6 TX+

A6 RX1- 5 TX-

A7 GND 4 GND

B5 TX1+ 2 RX+

B6 TX1- 3 RX-

B7 GND 1 GND

B8 SB0/SCLK/SCL 1 SCLK SGPIO

B9 SB1/SLOAD/SDA 2 SLOAD

B10 SB2/GND 4 GND

A9 SB3/GND

A10 SB4/SDATA_OUT/RS

3 SDATAOUT0

A11 SB5/SDATA_IN/ADD

A8 SB7/BP_TYPE

B11 SB6/CTLR_TYPE
