Electrical Characteristics

All power is supplied to the adapter via the PCI Express 3.3V and 12V rail. Necessary

Voltages are provided by onboard switching regulator circuitry operating off of 12V and

3.3V rails.

The following states determine the typical current consumption of the board:

• State 1. During BBU fast charge

• State 2. During initialization of all RAID 5 logical drives simultaneously

• State 3. While sitting idle at the DOS prompt.

— Supply voltage = 12V +/- 8% (from PCI edge connector only)

— Supply voltage = 3.3V +/- 9% (from PCI edge connector only)

— Actual power consumption.

Table 10. Actual Power Consumption Table

Note: +12V is used in the charging circuitry for the battery pack on the optional BBU Remote

card. If the BBU remote card is cable connected the following power consumption

figures apply:

1. During trickle charging of the battery pack: N/A (no trickle charge for Li-ION

2. During fast charging of the battery pack: 250mA rise in +12V current

Thermal and Atmospheric Characteristics

The maximum board temperature is limited by the LSI SAS2208 ROC Processor since it

uses the most power and will be the hottest component on the board.

Error Checking and Indication • Parity generation and checking, automatic consistency

checking

• Patrol reads

• Activity and fault LEDs

• Multiple retries

• Logs in NVRAM, event log, CIM, Smart, Intel

RAID

Web Console 2

Specification

Intel

Integrated RAID Module RMS25PB080,

RMS25PB040, RMS25CB080 and RMS25CB040

PCI Edge connector State1 State 2 State 3

3.3V supply 0.96A 0.86A 0.92A

+12V supply 0.81A 0.55A 0.56A

3.3V AUX. supply (BBU Applications only) 0.38A 0.2A 0.02A
