30 Intel® Integrated RAID Module RMS25PB0x0 and RMS25CB0x0 Hardware User’s Guide
Array Performance Features
Table 8. Array Performance Features
SAS/SATA bus speed Up to 6 Gbps per port, point-to-point
SAS/SATA ports • 2x4 internal port (RMS25PB080 and
RMS25CB080)
• 1x4 internal port (RMS25PB040 and
RMS25CB040)
Physical and virtual drive support 128 physical drives, 64 virtual drives, and 32
RAID arrays per controller
Cache 1 GB DDR3 1333 MHz SDRAM, optional
battery backup
Firmware 16 MB in reflashable flash ROM
Compatible devices • 2.5-inch and 3.5-inch SAS 2.0 or
SATA III
• Non disk devices including expanders
• Can support drives of mixed capacity
Cabling • Small, thin cables that do not restrict
airflow
• Shared connectors for multiple drives
Redundant configuration 128 KB NVRAM and config-on-disk (COD)
Enclosure management SGPIO
Enclosure support Assumes one SEP per enclosure
Specification
Intel
®
Integrated RAID Module
RMS25PB080, RMS25PB040,
RMS25CB080 and RMS25CB040
Specification
Intel
®
Integrated RAID Module RMS25PB080,
RMS25PB040, RMS25CB080 and RMS25CB040
Host data transfer rate Up to 8.0 Gigatransfer/sec per PCI Express* lane
Drive data transfer rate Up to 6.0 Gigabit/sec per PHY
Maximum scatter/gather 80 elements
Maximum size of I/O requests 6.4 Mbytes in 64 Kbyte stripes
Maximum queue tags per
drive
As many as the drive can accept
Stripe sizes 8, 16, 32, 64, 128, 256, 512, or 1024 KB
