Intel® Integrated RAID Module RMS25PB0x0 and RMS25CB0x0 Hardware User’s Guide 25

Host Board Interface

Intel

Integrated RAID Module RMS25CB080 and RMS25CB0400 board interface with

the host system through one custom board-to-board interface that implements one x8 PCI

Express* lanes signaling as defined in the PCI Express Specification 3.0. These interfaces

also provide +3.3 V power to the board.

Note: The modules will support PCI Express* Revision 3.0 at post launch.

Figure 14. PCI Interface

AF004606
