Asus ROG STRIX Z270E GAMING [10/106] Strix z270e gaming specifications summary
![Asus ROG STRIX Z270E GAMING [10/106] Strix z270e gaming specifications summary](/views2/1233191/page10/bga.png)
x
(continued on the next page)
STRIX Z270E GAMING specifications summary
Storage
Intel
®
Z270 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage
Technology 15 support
- 6 x SATA 6Gb/s ports
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280/22110 storage
devices support (both SATA & PCIE 3.0 x 4 mode)*
- 1 x M.2_2 Socket 3 with M key, type 2242/2260/2280 storage devices
support (PCIE 3.0 x 4 mode)**
- Ready for Intel
®
Optane Memory***
- Supports Intel
®
Smart Response Technology****
* The M.2_1 socket shares SATA_1 port when use M.2 SATA mode device. Adjust
BIOS settings to use a SATA device.
** The M.2_2 socket shares SATA_56 ports when use M.2 PCIE mode device in X4
mode. Adjust BIOS settings to use SATA devices.
*** Intel
®
Optane Technology only supported when using 7th Generation Intel
®
Processors. Before using Intel
®
Optane memory modules, ensure that you have
updated your motherboard drivers and BIOS to the latest version from ASUS
support website.
**** These functions will work depending on the CPU installed.
Audio
ROG SupremeFX S1220A 8-Channel High Definition Audio CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113 dB SNR
recording input
- SupremeFX Shielding Technology
- Dual Headphone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features:
- Sonic Radar III
- Sonic Studio III
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio
USB
Intel
®
Z270 Chipset*:
- 6 x USB 3.0 ports ( 4 ports at back panel [blue], 2 ports at mid-board)
- 6 x USB 2.0 ports *
* 2 x USB2.0 port at mid-board shares with ROG extension (ROG_EXT) port.
ASMedia
®
USB 3.1 controller*:
- 1 x USB 3.1 front panel connector**
- 2 x USB 3.1 ports (1 x Type-A [red] and 1 x Type-C at back panel)
* Supports 3A power output
** The USB 3.1 front panel connector shares bandwidth with PCIE_x1_2 and
PCIE_x1_4.
If the USB 3.1 front header is connected, PCIE_x1_2 and PCIE_x1_4 will be
disabled.
