xiii
STRIX Z270E GAMING specifications summary
Support DVD
contents
Drivers
ASUS Utilities
EZ Update
Anti-virus software (OEM version)
Operating
system support
Windows
®
10 64-bit
Windows
®
8.1 64-bit*
Windows
®
7*
* Windows
®
8.1 64-bit and Windows
®
7 32/64-bit are only supported when using
6th Generation Intel
®
Processors.
Form factor
ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm)
Specications are subject to change without notice. Please refer to the ASUS website for
the latest specications.
