STRIX Z270E GAMING specifications summary
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst Technology
Wireless &
Bluetooth
Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 GHz with
MU-MIMO support
Bluetooth v4.1, 4.0LE, 3.0+HS*
* Support for the Bluetooth specification depends on the Windows
®
version.
Windows
®
7/8.1 can support up to Bluetooth 4.0.
ASUS Special
Features
Performance Optimization
5-Way Optimization
- Whole system optimization with a single click! Perfectly consolidates
better CPU performance, power saving, digital power control, system
cooling and app usages.
Digi+VRM
EPU
- EPU
TPU
- Auto Tuning, TurboV, GPU Boost
Fan Xpert 4 featuring Fan Auto Tuning function and multiple
thermistors selection for optimized system cooling control
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
ASUS Q-Design
- Q-Shield
- Q-LED (CPU, DRAM, VGA, Boot Device LED)
- Q-Slot
- Q-DIMM
Gamer’s Guardian
- SafeSlot
- DIGI+ VRM
- DRAM Overcurrent Protection
- ESD Guards on VGA, LAN, Audio, KBMS and USB3.0/2.0 ports
- Highly Durable Components
- Stainless Steel Back I/O
ASUS Exclusive Features
- AURA Lighting Control
- 3D Printing Friendly design
- AI Suite 3
- AI Charger
