ASUS STRIX Z270E GAMING
1-7
Chapter 1
1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
causeyouphysicalinjuryanddamagemotherboardcomponents.
Slot No. Slot Description
1 PCIE_x1_1slot
2 PCIE_x16/x8_1slot
3 PCIE_x1_2slot
4 PCIE_x1_3slot
5 PCIE_x8_2slot
6 PCIE_x1_4slot
7 PCIE_x4_1slot
