xiv
Package contents
Check your motherboard package for the following items.
Motherboard STRIX Z270E GAMING
Cables
4 x SATA 6Gb/s cables
1 x SLI HB BRIDGE (2-WAY-M)
1 x RGB LED extension cable
Accessories
1 x I/O shield
1 x ASUS 2T2R dual band Wi-Fi moving antennas
(Wi-Fi 802.11a/b/g/n/ac compliant)
1 x CPU Installation tool
1 x ROG cable label set
1 x ROG Strix sticker
1 x 3D Printing Mount
1 x M.2 screws kit
1 x ROG Coaster
Application drive ROG motherboard support DVD
Documentation User guide
If any of the above items is damaged or missing, contact your retailer.
