Ryobi rbv3000vp 3001225 [11/148] English original instructions

Deutsch (Übersetzung der originalen Anleitungen)

English (Original instructions)

CE conformity

GOST-R conformity

SPECIFICATION

Type RBV2800S RBV3000VP

Voltage 220-240 V~

Frequency 50 Hz

Input Power 2800 W 3000 W

Insulation Class II

Air velocity 320 km/h 270-320 km/h

Air volume 14 m³/min 11-14 m³/min

Net weight

(without cable)

5.5 Kg

Mulching Ratio 15:1

Measured sound

pressure level;

:92.5 dB(A);

:2.0 dB(A)

Measured sound

power level;

:108 dB(A),

KwA=2 dB(A)

Vibration level a

: 4.6 m/s²; K:1.5 m/s²

DESCRIPTION

Figure 1

1. Shoulder Strap

2. Trigger

3. Rear handle

4. Livetool Indicator™

5. Quick change lever

6. Collection bag holder

7. Power Cord

8. Collection bag

9. Guide wheels

10. Front bracket

11. Lower tube

12. Upper tube

13. Front handle

14. Motor housing

15. Variable speed control (Model RBV3000VP only)

16. Tube lock button

Figure 2

17. Upper tube latch

18. Lower tube latch

Figure 3

16. Tube lock button

Figure 4

19. Bag connector with handle

20. Collection bag front hook

21. Shoulder strap connection hook

22. Debris Outlet Tube

ASSEMBLY

UNPACKING

 Carefully remove the product and any accessories

from the box.

 Inspect the product carefully to make sure no

breakage or damage occurred during shipping.

 Do not discard the packing material until you have

carefully inspected and satisfactorily operated the

product.

 If any parts are damaged or missing, please call your

Ryobi service centre for assistance.

 The blower vac is supplied with some

components not assembled. To assemble these,

proceed as follows:

ATTACHING AND EXTENDING THE TUBE (Fig. 2, 3)

 Slide the tube into the motor housing (14).

 Ensure that the latches (17 and 18) are closed and

securely hold the tube and motor housing together.

 Push the tube lock button down (16 in figure 3) and

pull the lower tube out of the upper tube by holding

the front bracket (10) to fully telescope the tubes out.

You will hear a >>click<< sound when the tubes are

fully extended and lock into place.

ATTACHING THE DEBRIS OUTLET TUBE(Fig.4a)

CAUTION:

Do not operate the machine without having

attached the debris outlet tube to the unit.

The debris outlet tube(22) is fixed by one time snap fit.

Insert the tube into motor housing(14), and it will be

locked into place when you push it to the end.

ATTACHING AND REMOVING THE COLLECTION BAG

(Fig. 4b)

CAUTION:

Do not use the product in vacuum/suction mode

without the collection bag fully assembled and

properly attached to the unit.

Align the front part of the plastic bracket on the

collection bag with the discharge outlet of the blower

vac (on the tube side)

 Align and push the bag connector on the rear side

(19) into the discharge outlet of the blower vac until it

clicks into place.
