ASUS PRIME Z370-A Series
1-7
Chapter 1
1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
causeyouphysicalinjuryanddamagemotherboardcomponents.
Slot No. Slot Description
1 PCIE3.0/2.0x1_1slot
2 PCIE3.0/2.0x16_1slot
3 PCIE3.0/2.0x1_2slot
4 PCIE3.0/2.0x1_3slot
5 PCIE3.0/2.0x16_2slot
6 PCIE3.0/2.0x1_4slot
7 PCIE3.0/2.0x16_3slot
