Asus PRIME Z370-A [52/104] Asus fan holder installation
![Asus PRIME Z370-A [52/104] Asus fan holder installation](/views2/1307885/page52/bg34.png)
2-12
Chapter 2: Basic Installation
Chapter 2
2.1.10 ASUS fan holder installation
To install the ASUS fan holder and fan
When using high performance settings whilst overclocking, ensure to install the fan holder
for additional fan(s).
• Youmayinstall12V(1A,12W),40mmx40mmfansor50mmx50mmfans.
• Ensuretotheusethebundledscrewsthatcamewithyourfans.
• Fansarepurchasedseparately.
