1-8
Chapter 1: Product Introduction
Chapter 1
• WerecommendthatyouprovidesufcientpowerwhenrunningCrossFireX™orSLI
®
mode.
• Connectchassisfanstothemotherboardchassisfanconnectorswhenusingmultiple
graphicscardsforbetterthermalenvironment.
• HyperM.2X16cardispurchasedseparately.
• EnabletheHyperM.2X16cardunderBIOSsettings.
VGA configuration
PCI Express 3.0 operating mode
PCIe 3.0/2.0 x16_1 PCIe 3.0/2.0 x16_2
SingleVGA/PCIecard
x16(singleVGA
recommended)
N/A
DualVGA/PCIecard x8 x8
Hyper M.2 X16 card
configuration
PCI Express 3.0 operating mode
PCIe 3.0/2.0 x16_1 PCIe 3.0/2.0 x16_2
2Intel
®
SSDonCPUsupport x8 x4+x4
3Intel
®
SSDonCPUsupport x8+x4+x4 N/A
