1-12
Chapter 1: Product Introduction
Chapter 1
2. CPU Over Voltage jumper (3-pin CPU_OV)
TheCPUOverVoltagejumperallowsyoutosetahigherCPUvoltageforaexible
overclockingsystem,dependingonthetypeoftheinstalledCPU.TogainmoreCPU
voltagesetting,insertthejumpertopins2-3.TogobacktoitsdefaultCPUvoltage
setting,insertthejumpertopins1-2.
3. 3D Mount
Secure3Dprintedpartstothese3DMountholesforapersonalizedmotherboard.
Download3Dsourcelesathttp://www.asus.com.
