xiii
(continued on the next page)
Internal I/O Ports
2 x AURA RGB headers
1 x AURA Addressable RGB header
1 x USB 3.1 Gen 2 front panel connector
1 x USB 3.1 Gen 1 header supports additional 2 USB 3.1 Gen 1
ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
6 x SATA 6Gb/s ports
1 x M.2_1 Socket 3 for M Key, type 2242/2260/2280 storage devices
support (Supports PCIE 3.0 x4 and SATA modes)
1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280 storage devices
support (Supports PCIE 3.0 x4 mode)
1 x 4-Pin CPU fan connector
1 x 4-Pin CPU_OPT fan connector
3 x 4-Pin Chassis fan connectors
1 x EXT_Fan header
1 x 4-Pin W_PUMP+ connector
1 x W_IN header
1 x W_OUT header
1 x W_FLOW header
1 x 4-Pin AIO_PUMP connector
1 x H_AMP fan connector
1 x Thermal sensor connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x Start button
1 x Reset button
1 x Safe Boot button
1 x Retry button
1 x LN2 mode jumper
1 x Slow mode switch
1 x MemOK! Button
1 x Front panel audio connector (AAFP)
1 x TPM connector
1 x System panel connector
BIOS
1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0,
SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash
3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control,
F3 My Favorites, Last Modied log, F12 PrintScreen, F3 Shortcut
functions and ASUS DRAM SPD (Serial Presence Detect) memory
information.
Manageability
WfM2.0, DMI3.0, WOL by PME, PXE
MAXIMUS X HERO (WI-FI AC) specifications summary
