ROG MAXIMUS X HERO (WI-FI AC)
1-19
Chapter 1
6. CPU, CPU optional, high amp, extension, and chassis fan connectors; water
pump+, and AIO pump connectors (4-pin CPU_FAN; 4-pin CPU_OPT; 4-pin H_
AMP; 5-pin EXT_FAN; 4-pin W_PUMP+; 4-pin AIO_PUMP; 4-pin CHA_FAN1-3)
Connectthefancablestothefanconnectorsonthemotherboard,ensuringthatthe
blackwireofeachcablematchesthegroundpinoftheconnector.
• DONOTforgettoconnectthefancablestothefanconnectors.Insufcientairow
insidethesystemmaydamagethemotherboardcomponents.Thesearenotjumpers!
Donotplacejumpercapsonthefanconnectors!
• Ensuretofullyinsertthe4-pinCPUfancabletotheCPUfanconnector.
• ForbetterQ-Fanfunctions,werecommendusing4-pinPWMfanswhenyouconnect
powerfulfans(1Aorabove)ontotheH_AMP_FANconnector.
• EnsuretodisableQ-Fanfunctionsifyouwanttoconnectpowerful3-pinDCfans(1A
orabove)ontotheH_AMP_FANconnector.
• Connectthepumpcablefromtheall-in-onecooler(AIOcooler)totheAIO_PUMP
header,andconnectthefancablestotheCPU_FANand/orCPU_OPTheader(s).
• W_PUMP+functionsupportdependsonwatercoolingdevice.
