Asus ROG MAXIMUS X HERO (WI-FI AC) [16/116] Installation tools and components

xvi

Installation tools and components

1 Bag of screws Phillips (cross) screwdriver

PC chassis Power supply unit

Intel

LGA 1151 CPU Intel

LGA 1151 compatible CPU Fan

DDR4 DIMM SATA hard disk drive

SATA optical disc drive (optional) Graphics card (optional)

The tools and components in the table above are not included in the motherboard package.
