Asus ROG MAXIMUS X HERO (WI-FI AC) [81/116] Chapter 3

ROG MAXIMUS X HERO (WI-FI AC)

3-19

Chapter 3

M.2_1 Configuration: [Auto][SATA mode][PCIE mode]

[Auto] Auto-detects the M.2 device mode. If a SATA device is detected,

SATA6G_1 will be disabled.

[SATA mode] Only supports M.2 SATA devices. Please note that SATA6G_1 port cannot

be used in this mode.

[PCIE mode] Only supports M.2 PCIE devices.

M.2_2 PCIe Bandwidth Configuration: [X2][X4]

[X2] Run at X2 mode with SATA6G_56 enabled.

[X4] Run at X4 mode for higher performance with SATA6G_56 disabled.

USB Type C Power Switch

[Auto] The system will automatically detect your USB Type C devices and provide

suitable power if needed.

[Enabled] The USB Type C port will always provide power to your devices.

RGB LED lighting

When system is in working state

This item allows you to turn the RGB LED lighting on or off when the system is in the

working state.

Conguration options: [On] [Off]

When system is in sleep, hibernate or soft off states

This item allows you to turn the RGB LED lighting on or off when the system is in the

sleep, hibernate or soft off states.

Conguration options: [On] [Off]

Bluetooth Controller

This item allows you to enable or disable the Intel Bluetooth controller.

Conguration options: [Disabled] [Enabled]

Wi-Fi Controller

This item allows you to enable or disable the Intel Wi-Fi 802.11ac controllers.

Conguration options: [Disabled] [Enabled]

Intel LAN Controller

This item allows you to enable or disable the Intel LAN controllers.

Conguration options: [Disabled] [Enabled]
