1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
causeyouphysicalinjuryanddamagemotherboardcomponents.
Slot No. Slot Description
1 PCIex1_1slot
2 PCIex16/x8_1slot
3 PCIex1_2slot
4 PCIex8_2slot
5 PCIex1_3slot
6 PCIex4_3slot
