Projecting an Image

Position

(Lens shift)

Position

Adjusting the tilt of the projector

with the feet

You can adjust the height of the projector

using the feet.

By changing the tilt of the projector with feet,

you can adjust the position of the projected

image.

• Be careful not to let the projector down on

your fingers.

• Do not push hard on the top of the projector

with the foot extended.

Lens shift

dial V

For adjusting lens shift, turn each dial with

your hand, screwdriver, etc.

Lens shift

dial H

Foot
