35
Notes When Using PC Free Interactive Function (VPL-SW636C only)
Adjustments and Settings Using a Menu
Notes When Using PC Free Interactive
Function (VPL-SW636C only)
When using the PC Free Interactive function, the items of the Picture menu and the Screen
menu work to the background images from the external devices. However, they do not work to
the drawing data with Interactive Pen Device or the whiteboard mode. For detatils, see the list
below.
When“Interactive Mode” is set to “PC Free,” the functions of the items listed below are also limited.
Items
Enabled, or disabled for the drawing data and
the whiteboard mode
Picture menu
(page 22)
Picture Mode Disabled
Reset Disabled
Contrast Disabled
Brightness Disabled
Color Disabled
Hue Disabled
Color Temp. Enabled
Sharpness Disabled
Expert Setting Gamma
Mode
Disabled
Screen menu
(page 23)
Aspect Disabled
Adjust Signal
APA Disabled
Phase Disabled
Pitch Disabled
Shift Disabled
Items Descriptions
Connection/
Power menu
(page 30)
ECO Lamp Mode When you select “Auto,”the effectiveness of it
becomes equivalent to “Standard.”
Auto Power
Saving
With No
Input
Even when you select an option other than “Off,”
the effectiveness becomes equivalent to “Off.”
With Static
Signal
Installation
Menu
(page 33)
Digital Shrink Disabled for PC Free Interactive or mouse mode.
