31
The Connection/Power Menu
Adjustments and Settings Using a Menu
*1: This may not be optimum depending on the input signal. In this case set manually according
to the connected equipment.
*2: When “Standby Mode” is set to “Low,” the network and network control function cannot be
operated while the projector is in standby mode.
*3: This varies depending on the “Lamp Mode” setting.
*4: As the lamp is dimmed gradually, you may not notice any change in brightness. You might only
notice that the lamp has dimmed when its brightness is restored after there is a change in input
signal.
*5: This mode does not work for about three minutes after the lamp lights. A change in signal may
not be detected depending on the input image. The lamp may become brighter at intervals
during lamp dimming. However, this is not a malfunction. If With No Input is set, it takes
priority.
ECO
Lamp Mode High/Standard/Low/Auto
*5 *7 *15
: When set to “High,” the image
becomes brighter, and power consumption becomes higher. When set to
“Low,” power consumption is minimized; however, the image will be
darker. When set to “Auto,” brightness is adjusted automatically
according to image content. Dark images are projected with brightness
adjusted, leading to energy-saving. Bright images are projected
brightly, without adjusting brightness.
Constant
Brightness
On/Off: Available when the lamp mode is set to High. Outputs light at
a certain brightness.
*13
Auto Power Saving
With No Input
*16
Lamp Cutoff: The lamp turns off automatically and power
consumption is reduced if no signal is input for approx. 10 minutes.
The lamp lights again when a signal is input or any key is pressed. In
Lamp Cutoff, the ON/STANDBY indicator lights in orange. (page 73)
Standby*
6
: If no signal is input to the unit for approx. 10 minutes, the
power turns off automatically, and the unit enters standby mode.
Off: You can deactivate the With No Input.
With Static
Signal
*17
Lamp Dimming
*4 *5 *7
: If an image does not change for about 10
seconds, lamp output is gradually reduced (approximately 10% to
15%*
3
) from that set in the Lamp Mode. Automatically the lamp slowly
darkens to approximately 30% of its lamp output according to the
selected time (with no change to input signal) “5,” “10,” “15,” “20”
minutes or “Demo.,” While dimming the lamp, the message “Lamp
Dimming” appears. If you select “Demo.,” the image will start to
darken about 40 seconds later. When any change in signal is detected,
or an operation (remote control or control panel) is performed, normal
brightness is restored.
Off: You can deactivate the With Static Signal.
Standby Mode*
2
Standard/Low: When set to “Low,” lowers power consumption in
Standby mode.
Direct Power On On/Off: When set to “On,” you can turn the power on without going to
Standby mode when the AC power cord is connected to a wall outlet.
With the projector turned off, you can also unplug the AC power cord
without going to Standby mode, regardless of the Direct Power On
setting.
*19
Notes
Items Item descriptions
