BLIZZARD
USE AND MAINTENANCE MANUAL
428000396
137
EN
UPRIGHT DISPLAY CABINETS
5. TECHNICAL SPECIFICATIONS
This equipment is exclusively intended to display and sell pre-packaged ice creams
and frozen products.
The manufacturer is not liable for injury to persons or damage to property or the equipment
itself caused by the displaying of products other than those described above.
Attention
- Food preservation.
- Displaying and/or preserving non-food products (chemicals, pharmaceuticals, etc).
