14
BLIZZARD
USE AND MAINTENANCE MANUAL
428000396
137
EN
UPRIGHT DISPLAY CABINETS
5.1 Installation (Technical dimensions mm)
Attention
The distances indicated for correct equipment installation must be respected.
