BLIZZARD
USE AND MAINTENANCE MANUAL
428000396
137
EN
UPRIGHT DISPLAY CABINETS
2. SAFETY
The buyer is responsible for training personnel using the appliance on the risks, safety devices
and general health and safety rules required by the laws of the country where the equipment is
installed.
Users/operators should be aware of the position of all the controls and how they work, as well as
of the features of the equipment.
They should also read this manual in its entirely.
Maintenance work should be conducted by qualifi ed personnel after the equipment has been
prepared adequately.
Danger
Tampering with or unauthorised replacement of one or more parts of the equipment, applying ac-
cessories that modify its use and fi tting spare parts other than recommended ones may result in
accident risks.
Danger
Before doing any type of work, the equipment must always be disconnected from the power supply.
Any work on electric parts or cooling system components should only be carried out by
trained personnel in compliance with current laws.
2.1 Personnel training
The buyer is responsible for ensuring personnel who will use the equipment and
maintenance technical staff are instructed and trained adequately.
The manufacturer is available for advice, clarifi cations, etc. so that the operator and
technical staff can use the equipment correctly.
Attention
The equipment is intended for professional use.
2.2 Safety devices applied
The Equipment is equipped with the following safety devices:
2.2.1 SAFETY DEVICES PRESENT
2.2.2 FIXED PROTECTIVE DEVICES
2.2.3 SECTIONING THE ELECTRICITY SUPPLY
2.2.1 Safety devices present
Devices which operation prevents risk situations in operation conditions verifying (e.g.
fuses, pressure switches, protective devices, circuit breakers, etc.).
2.2.2 Fixed protective devices
Fixed protective devices consist of fi xed perimeter shields, which are used to prevent
external parts from entering the equipment.
Danger
It is strictly forbidden to start up the equipment after maintenance work without refi tting the panelling
properly.
Attention
You should check the integrity of fi xed panels and corresponding fi xings to the frame, focusing in
particular on the protective panels.
