ISA Blizzard 1P RV TB [9/30] Refrigerant r290
![ISA Blizzard 1P RV TB [9/30] Refrigerant r290](/views2/1335874/page9/bg9.png)
9
EN
BLIZZARD
USE AND MAINTENANCE MANUAL
428000396
137
UPRIGHT DISPLAY CABINETS
2.5 Refrigerant R290
This equipment contains a small amount of R290 refrigerant, an environmentally
compatible gas, but one that is highly fl ammable. Be very carefully during transport,
installation of the equipment and disposal to not damage the refrigerant circuit pipes.
Maintenance must be performed by qualifi ed personnel who have been trained and
authorised to work with fl ammable refrigerants.
IN THE EVENT OF DAMAGE:
Keep the equipment far from fl ames or sources of ignition. Ventilate the room for several
minutes. Turn the equipment off and disconnect the power supply cord. Inform customer
service. The more refrigerant the equipment contains, the bigger the room must be where
the equipment is installed. In rooms that are too small, a fl ammable mixture of air and gas
can form in the event of leakage. The volume of the room where the equipment is
located must be at least 19 m³ for each chiller system present.
USE:
Never use electrical equipment inside this equipment. Do not damage the refrigerant
circuit. Do not use mechanical devices or other means to accelerate the defrosting process
other than those recommended by the manufacturer. Keep the ventilation openings in the
equipment housing or structure free of obstructions.
DANGER OF EXPLOSION:
Do not store products containing combustible gas propellents and explosive substances
inside the equipment.
INSTALLATION OF THE EQUIPMENT:
A dry, ventilated area is best for installation. The installation area must not be exposed
to direct sunlight and must not be near heat sources such as stoves, heaters, etc. If
installation next to a heat source is unavoidable, use a suitable insulating panel.
ELECTRONIC CONTROL UNIT:
The set-up for refrigerant R290 control unit must only be replaced with ISA supplied
original spare part.
