ISA Blizzard 1P RV TB [13/30] Technical specifications
![ISA Blizzard 1P RV TB [13/30] Technical specifications](/views2/1335874/page13/bgd.png)
13
EN
BLIZZARD
USE AND MAINTENANCE MANUAL
428000396
137
UPRIGHT DISPLAY CABINETS
5. TECHNICAL SPECIFICATIONS
1P 2P 3P
RV TB RV TB RV TB
External dimensions
Lenght mm
670 1340 2010
Depth mm
885
Heght mm
2071
Refrigeration Ventilated
Defrosting Hot Gas
Climate class
N°
3
Environmental conditions
°C / %RH
25 / 60
Product class L1
Safety class (CEI EN 60335-2-89)
N° / °C
5 / 43 ± 2°C
Refrigerant R404A R290 R404A R290 R404A R290
Power supply
V / ph / Hz
230 / 1 / 50
Electric absorption
Standard W / A
680 / 3.9 1000 / 4.8 1360 / 7.7 2000 / 9.5 2040 / 11.6 3000 / 14.3
Electric absorption
Defrosting W / A
980 / 5 1080 / 4.6 1960 / 9.9 2150 / 9.2 2940 / 14.8 3220 / 13.8
Weight (net)
Kg
170 310 490
