![ISA Blizzard 1P RV TB [17/30] Structure](/views2/1335874/page17/bg11.png)
17
EN
BLIZZARD
USE AND MAINTENANCE MANUAL
428000396
137
UPRIGHT DISPLAY CABINETS
6. EQUIPMENT DESCRIPTION
To ensure the operator's safety, equipment devices should be kept in constant working order. This
manual is intended to illustrate the use and maintenance of the equipment. The operator has a
responsibility and duty to carefully observe its instructions.
6.1 Structure
The equipment consist of a single piece of furniture which contains all the operational devices
necessary to make it a professional and effi cient product for its intended use.
The equipment consists of:
• Insulated structure in ecological polyurethane
• LED lighting
• Cooling system at ventilated refrigeration
• Glass door
• Electronic commands panel
• Electrical system
• On board condensing unit
• Height adjustable feet
• Adjustable shelves
1 Symbols of Compliance
2
Identifi cation
of Company
Product Manager
3 Production Order
4 Type
5 Model Name
6 Article
7 Serial Number
8 Production Date
9 - 10
Power supply
Voltage and Frequency
11 Gross Capacity
12 Absorption at Rated Capacity
13 Absorption during Defrosting
14 Absorption of Heating Elements
15 Lamp Power
16 Fuse Value
17 Climate Class
18 Number of Motors
19 Type of Coolant
20 Amount of Coolant
21 Safety Class
22 - 23 Customer order
24 WEEE Mark
6.2 Identifi cation
