1. NOTES / IMPORTANT NOTES
The content of this manual is of technical nature and is owned by ISA S.r.l.. It is forbidden
to reproduce, circulate or modify all or part of its content without written consent. Any
infringement will be legally pursued.
The manual and the conformity certifi cate are an integral part of the equipment and should
always accompany the product in the event of transferral to a new location or to a new owner.
The user is responsible for the integrity of these documents, for their consultation during
the whole life cycle of the equipment itself. Keep this manual in a safe place. It should be
made available near the equipment for consultation at any time. If lost or destroyed, you
can request a copy of the manual to ISA S.r.l. by specifying the exact model, identifi cation
number and year of manufacturing. The manual refl ects the manufacturing technology at
the time of supply. The manufacturer reserves the right to modify its products in any way it
deems necessary, with no obligation to update manuals and machines relating to previous
manufacturing batches.
This equipment is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities or by persons lacking the necessary experience and knowledge,
unless they are supervised by a person responsible for their safety who has instructed them
on how to use the cabinet. Children should be supervised to ensure that they do not play
with the equipment. Always refer to this manual before going ahead with any operation.
Before doing any type of work, disconnect the equipment from the power supply. Any work
on electric and electronic parts or cooling system components should only be carried out by
trained personnel in compliance with current laws.
The Manufacturer cannot be held liable for any injury to persons or animals, or damage to the
product itself in the event of:
• Improper use of the equipment or use of the appliance by unqualifi ed or unauthorised
personnel.
• Failure to comply with current legislation.
• Incorrect installation and/or power supply faults.
• Failure to observe the instructions contained in this Manual.
• Failure to follow the maintenance programme.
• Unauthorised modifi cations.
• Installation of non-original spare parts in the equipment.
• Installation and use of the equipment for purposes other than those for which the
appliance was designed and sold.
• Tampering with or damage to the power supply cable.
Liability for applying the safety instructions contained in this manual is held by the technical
personnel responsible for the intended use of the equipment, who should ensure that
authorised personnel:
• Are qualifi ed to carry out the requested activity.
• Are aware of, and carefully comply with, the instructions contained in this document.
• Are aware of, and apply, the general safety standards applicable to the equipment.
Failure to comply with safety standards may result in injury to personnel and damage to the
equipment components and control unit. The user can contact the dealer to request additional
information not contained in this document, or suggest improvements, at any time.
Before the product is delivered to the customer, it is essential that a trained technical
member of staff checks that the equipment is operating correctly in order to achieve
maximum performance.
