22
BLIZZARD
USE AND MAINTENANCE MANUAL
428000396
137
EN
UPRIGHT DISPLAY CABINETS
Any work conducted on the on the equipment MUST involve disconnection from the power socket and in
any case, none of the protective elements (grid, casing) should be removed by non-qualifi ed staff; the
equipment should not be operated when these protective elements have been removed.
The Equipment manager must check and respect the maintenance schedule in the table below by
calling the authorised Technical Assistance service when indicated.
9. MAINTENANCE
ROUTINE
OPERATION FREQUENCY AUTHORISED
PERSONNEL
Cleaning the external surfaces Depending upon Use and Necessity User
Cleaning the accessible internal parts
(without the use of tools)
Depending upon Use and Necessity User
Power supply cable,
electric sockets and/or plugs check
Monthly/Six monthly User
Check the seal gaskets integrity Monthly User
Condenser cleaning Monthly/Six monthly Technical
Assistance
Check the compressor oil level
(if present)
Six-monthly Technical
Assistance
Air tank draining
(if present)
Six-monthly Technical
Assistance
Check pneumatic connections
(if present)
Six-monthly Technical
Assistance
Check the integrity of chiller system piping Six-monthly Technical
Assistance
Inspect cables and internal power
connections
Six-monthly Technical
Assistance
Cleaning of condensation absorbing sponges
(if present)
Six-monthly Technical
Assistance
EXTRAORDINARY
OPERATION AUTHORISED
PERSONNEL
Replacing lamps/LED
(if present)
Technical
Assistance
Replacing control panel
(electronic control board - thermostat - etc.)
Technical
Assistance
Replacing power supply cable,
electric sockets and/or plugs check
Technical
Assistance
