13
Choice of working tool depends on processed material and type of
planned task. Cutter bits made of high speed steel (HSS) are designed
for processing soft materials, like plastics or soft wood. Cutter bits
made of sintered carbide (HM) are designed for processing harder
materials, e.g. hard woods, chipboards, or even aluminium if allowed
by the cutter bit manufacturer.
Use only working tools whose allowable rotary speed is higher or
equal to maximum power tool speed with no load.
INSTALLATION OF WORK TOOLS
Disconnect the power tool from power supply.
Use protective gloves for installation and removal of working
tools.
• Lower the spindle guard (4).
• Press and hold the spindle lock button (2). If necessary, turn the
spindle (3) by hand until the lock engages. Depending on the
working tool shaft diameter, use appropriate collect sleeve (19).
Bear in mind the spring (18) that operates with it. When replacing
the collet sleeve, start with putting the spring (18) into the
spindle, then collet sleeve (19) of appropriate size. Then lock them
in place by installing the fixing nut (20).
• Slide the working tool shank into the spindle to at least 20 mm
depth.
• Tighten the fixing nut (20) with the flat key (37) (g. C).
• Release the spindle lock button (2).
• Set up the spindle guard (4).
Tighten the xing nut with the at key only when there is a
working tool inside the spindle. Otherwise handle the xing nut
gently and only by hand, to avoid damage to the collet sleeve.
INSTALLATION OF DUST EXTRACTION ADAPTER
You can protect yourself from dust by using anti-dust mask and
appropriate device for dust extraction.
Disconnect the power tool from power supply.
Remove working tool before installing dust extraction adapter
(31) (g. B).
• Loosen the plunge guide locking lever (15) to set the router
spindle in upper position.
• Place the dust extraction adapter (31) in the base (5) and fix with
adapter fixing screws (30) (g. B), by driving them from below.
• Connect dust extraction hose to the dust extraction adapter (31)
either directly or use reducing connector (32), depending on the
connector diameter of the hose.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the router
rating plate.
The router is equipped with the switch lock button that protects
against accidental start up.
Switching on
• Press the switch lock button (24).
• Press and hold the switch (23).
Switching o
• Release pressure on the switch button (23).
Illumination
The device is equipped with illumination feature (17) that improves
visibility in the workplace. Illumination turns on automatically when
the device is turned on.
ADJUSTMENT OF SPINDLE ROTATIONAL SPEED
Wheel for rotational speed control (25) is located on the router body.
Select spindle speed depending on your needs (depending on the
cutter bit used, hardness of processed material, type of work etc.).
The below table is a user's guideline and shows exemplary settings.
Material Cutter size
Setting of speed
adjustment wheel
Aluminium
4-15 mm
14-40 mm
1-2
1
Plastics
4-15 mm
16-40 mm
2-3
1-2
Chipboard
4-10 mm
12-20 mm
22-40 mm
3-6
2-4
1-3
Soft wood, e.g.
pine, spruce
4-10 mm
12-20 mm
22-40 mm
5-6
3-6
1-3
Hard wood, e.g.
oak, beech
4-10 mm
12-20 mm
22-40 mm
5-6
3-4
1-2
Select setting after performing practical test. It is recommended
to do a few initial try cuts on waste material before commencing
the planned work with the target material.
When working with low rotational speed for a long time it is
recommended to cool down the device. To do that, start the
power tool with no load and keep it going at full speed for
approximately 1 minute.
ROUTER PLUNGING
• Place the router on even surface.
• Unlock the plunge guide locking lever (15).
• Hold the handles with both hands and press the tool downwards,
overcoming the spring resistance.
• Release the pressure, springs will automatically return the router
body to default (upper) position.
SETTING THE CUTTING DEPTH
Disconnect the power tool from power supply.
• Place the router on even surface.
• Unlock the plunge guide locking lever (15).
• Overcome the spring resistance and bring down the router body,
so the cutter bit touches surface the router is placed on.
• Lock the tool in the position with the plunge guide locking lever
(15).
• Loosen the depth gauge locking knob (9).
• Pull down the depth gauge (10) so it contacts one of the surfaces
of the depth gauge stepped bumper (7).
• When necessary, reset the depth gauge indicator (11) by shifting
it on the depth gauge (10).
• Put the depth gauge (10) at the height that corresponds to
required cutter bit plunging in processed material. Use the main
scale (12) on the router body. Then tighten the depth gauge
locking knob (9) to lock the setting.
You can set cutting depth precisely by turning knob for precise
depth adjustment (14). A full turn of the knob shifts the router body
vertically by 1.5 mm as shown by the precision scale (13) and scaling
every 0.1 mm. Range of depth adjustment is +/- 8 mm, which is
carried out by lifting or lowering the cutter body in relation to the
depth gauge stepped bumper (7). This causes reduction or increase
