Page 47
Dimensions - RT4D 100 & 140
RT4D 100 RT4D 140
A 5400 5400
A1 80 80
A2 150 150
A3 1785 1785
A4 800 800
A5 2585 2585
RT4D 100 RT4D 140
C1 80 80
C2 480 640
C3 1455 1295
C4 1680 1080
C5 1705 1160
D 120 120
A
A4A3
A2A1
A5
C3C2C1
B2
B1
B3
B4
B5
C4 C5
D
B
Outdoor coil
Indoor coil
Supply air
QE
Return air
Return airMain filter Filter Exhaust air
blowers
Outdoor airElectrical inlet (floor) Outdoor air
Electrical and compressor cabinet
C1+C2+C3
A5 A4 A1+A2+A3
Hole Ø45 mm
lifting point
Compressor
cabinet
VH4
Exhaust
plug-fans
Outdoor air
Exhaust air
Exhaust air
Supply air
Electrical supply
(sideway)
Electrical board
Drain connection
Supply
air blower
Indoor coil Air filter Exhaust air blowers
Supply air
QE
C1 SL
C4
H2
H1
60
100
100
2 metres
H2
H1
B3+B4+B5 B2
B
H
B1
A
C5
Return airElectric heater
RT4D 100 RT4D 140
B 1960 1960
B1 390 350
B2 560 640
B3 710 670
B4 200 200
B5 100 100
RT4D 100 RT4D 140
E 1100 1100
H 1880 1880
H1 690 610
H2 480 640
H3 1400 1400
H4 220 220
