TD-W8960NB 300Mbps Wireless N ADSL2+ Modem Router User Guide

Figure 4-20

4.4.3 LAN

Choose “Advanced Setup”Æ“LAN”, and you will see the LAN screen (shown in Figure 4-21), the

section allows you to configure the Router’s LAN ports settings.
