TD-W8960NB 300Mbps Wireless N ADSL2+ Modem Router User Guide
4.4.2.5 ATM-IPoA
If your ISP provides an IPoA connection and you need to use an ATM Interface, follow the steps
below to add a WAN service over a selected ATM interface.
1. Add a new ATM interface and select IPoA option for DSL Link Type (see 4.4.1.1
ATM
interface).
2. Click the Add button on the screen Figure 4-7 and the next configuration is similar to IPoE
(see section 4.4.2.2
ATM-EoA-IPoE). The difference is that you have to manually set the
Static IP Address on the screen of Figure 4-15, and the Static IP Address for DNS Server on
the screen of Figure 4-18.
)
Note:
ETH and ATM service can not coexist. If the ATM Interface had configured, you cannot configure
any other WAN service over the ETH Interface until the ATM Interface is deleted.
4.4.2.6 ETH-PPPoE
If your ISP provides a PPPoE connection and you need to use an ETH Interface, follow the steps
below to add a WAN service over a selected ETH interface:
1. Add a new ETH interface on the screen of 4.4.1.2
ETH interface.
2. Click the Add button on the screen Figure 4-7 and the following configuration is similar to
PPPoE over ATM interface (see section 4.4.2.1
ATM-EoA-PPPoE).
4.4.2.7 ETH-IPoE
If your ISP provides an IPoE connection and you want to use an ETH Interface, follow the steps
below to add a WAN service over a selected ETH interface:
1. Add a new ETH interface on the screen of 4.4.1.2
ETH interface.
2. Click the Add button on the screen Figure 4-7 and the next configuration is similar to IPoE
over ATM interface (see section 4.4.2.2
ATM-EoA-IPoE).
4.4.2.8 ETH-Bridge
If you want to adopt the Bridge service and you need to use an ETH Interface, follow the steps
below to add a WAN service over a selected ETH interface:
1. Add a new ETH interface on the screen of 4.4.1.2
ETH interface.
2. Click the Add button on the screen Figure 4-7 and the next configuration is similar to Bridge
over ATM interface (see section 4.4.2.3
ATM-EoA-Bridg).
)
Note:
For ETH-PPPoE, ETH-IPoE and ETH-Bridge, the Bridging option will display in the screen of
Figure 4-20 only when VLAN MUX Mode is selected for Connection Mode on the screen of Figure
4-5. You have to set the 802.1P Priority and 802.1Q VLAN ID.
28
