TD-W8960NB 300Mbps Wireless N ADSL2+ Modem Router User Guide

¾ Disable/Enable: Select the Enable to log the events, if you don’t want to log these events,

please select Disable.

¾ Log Level: Select the Log level in the drop-down list, for the Log level, all events above or

equal to the selected level will be logged.

¾ Display Level: Select the Display level in the drop-down list, for the Display Level, all logged

events above or equal to the selected level will be displayed.

¾ Mode: Select the mode to record the events. If the selected mode is Local, events will be

recorded in the local memory. If the selected mode is Remote, events will be sent to the

specified IP address and UDP port of the remote system log server. If the selected mode is

Both, events will be sent to the local memory and the remote system log server.

¾ Server IP Address: Type the address of the server you want to record the events.

¾ Server UDP Port: Type the UDP Port of the server.

4.7.3 SNMP Agent

Choose “Management”Æ“SNMP Agent”, you can see the SNMP-Configuration screen as shown

below.

SNMP (Simple Network Management Protocol) has been widely applied in the computer networks

currently, which is used for ensuring the transmission of the management information between

any two nodes. In this way, network administrators can easily search and modify the information

on any node on the network. Meanwhile, they can locate faults promptly and implement the fault

diagnosis, capacity planning and report generating.

An SNMP Agent is an application running on the Router that performs the operational role of

receiving and processing SNMP messages, sending responses to the SNMP manager, and

sending traps when an event occurs. So a Router contains SNMP "agent" software can be

monitored and/or controlled by SNMP Manager using SNMP messages.

An SNMP Manager or SNMP Service is an application that performs the operational roles of

generating SNMP messages/requests to modify and retrieve management information, and

receiving the requested information and trap-event reports that are generated by the SNMP agent.

SNMP Manager is the third-party management system. Monitor one is an SNMP Manager.

Figure 4-103
