724/725/726
Calibration Manual
12
General Specifications
Operating temperature
724 and 725
726
-10 °C to 55 °C
-10 °C to 50 °C
Storage temperature - 20 °C to 70 °C (limited by battery storage
specifications)
Stability ± 0.005 % of range/°C outside of 23 ± 5 °C
Operating altitude 3000 meters above mean sea level
Relative Humidity (% RH operating without
condensation)
90 % (10 to 30 °C)
75 % (30 to 40 °C)
45 % (40 to 50 °C)
35 % (50 to 55 °C)
uncontrolled < 10 °C
Vibration Random, 2 g, 5 Hz to 500 Hz
Safety and EMC
IEC 61010-1, IEC 61010-2-030, Pollution Degree 2
IEC 61326-1 (Portable), CISPR 11 (Class A)
Power requirements 4 AA alkaline batteries
Protection Class Pollution Degree II
Electromagnetic Compatibility
Applies to use in Korea only. Class A Equipment
(Industrial Broadcasting & Communication
Equipment
[1]
[1]
This product meets requirements for industrial
(Class A) electromagnetic wave equipment and the
seller or user should take notice of it. This equipment
is intended for use in business environments and is
not to be used in homes.
Size 96 x 200 x 47 mm (3.75 x 7.9 x 1.86 in)
Weight 650 g (1 lb, 7 oz)
Cleaning the Calibrator
Warning
To avoid electric shock or damage to the Calibrator, never allow water
inside the Calibrator’s case.
If the Calibrator requires cleaning, wipe it down with a cloth that is lightly dampened with
water or a mild detergent.
Do not use aromatic hydrocarbons, chlorinated solvents, or methanol-based fluids when
cleaning the Calibrator. To avoid damaging the case, never apply solvents to the
Calibrator.
