8
English
Troubleshooting
Often, what appears to be a malfunction is due to user error. Before calling for service, please consult the following table.
Speci cations
Design and speci cations are subject to change without notice.
Maximum output ............................................................. 250 W
Frequency response ............................................ 35 Hz–150 Hz
Cut-o frequency ................................................. 50 Hz–125 Hz
Phase ................................................................................0˚, 180˚
Input sensitivity / impedance
LINE IN ............................................................ 125 mV / 22 kΩ
Power ....................... DC 14.4 V (Operating voltage 11 V–16 V)
Current consumption ..........................................................10 A
Sen sitivi ty .......................................................................... 81 dB
Dimensions ....................................... Width : 350 mm (13-3/4”)
Height : 75 mm (2-15/16”)
Depth : 240 mm (9-7/16”)
Weight ...................................................................4.2 kg (9.3 Ib)
Problem Cause Remedy
Power cannot be
turned on (illumina-
tion does not light).
• The fuse is blown.
• Check the ⊕/⊖ polarity of the power cord and
that the cords are not shorted, then replace with
a fuse with the rated capacity.
• Re-connect the cords correctly by referring to
the connection example (on page 4, 5).
• The power supply pin (yellow) of the 10-pin con-
nection cord is not connected.
• Connect the cord correctly by referring to the
connection example (on page 4, 5).
• Attach the grounding terminal to the metallic
section of the vehicle (not a coated surface) by
tightly screwing it.
• Insert the connector all the way in.
• Check the connections of all cords, then connect
the ⊖ cable to the battery.
• The power control pin (blue/white) of the 10-pin
connection cord is not connected.
• The grounding pin (black) of the 10-pin connec-
tion cord is not connected.
• The 10-pin connector is not plugged in completely.
• The negative ⊖ cable of the car battery is
disconnected.
• Check the connections of all cords, then connect
the ⊖ cable to the battery.
No sound
• The attenuator of the audio components is set to
ON.
• Switch the attenuator OFF.
• The VOLUME control is set to the MIN position. • Increase the volume to an optimum level (on
page 7).
• The speaker cords are connected improperly. • Connect the cords correctly by referring to the
connection example (on page 4).
• Connection terminals are connected improperly. • Insert the connectors or jacks all the way in to
the terminals.
Sound is small.
• The input level is set to low. • Turn the VOLUME control knob and set the input
level to an optimum level.
• Connection terminals are connected improperly. • Plug the cord into the REMOTE terminal.
• Check that the RCA cord is connected properly.
• Large power input causes the protection circuit
for this unit to operate.
• Turn the volume to MIN for a while.
Sound quality is bad
(sound is distorted).
• The input level is set to high. • Turn the VOLUME control knob and set the input
level to an optimum level.
Sound is unnatural.
• The speaker cords are connected with incorrect
positive ⊕/negative ⊖ polarity.
• Connect the cords correctly by referring to the
connection example (on page 4, 5).
• Attach the grounding terminal to the metallic
section of the vehicle (not a coated surface) by
tightly screwing it.
• The grounding pin (black) of the 10-pin connec-
tion cord is poorly contacted.
Remote control does
not work.
• The remote control cord is unplugged. • Plug the cord into the REMOTE terminal.
• Insert the connector all the way in.
The illuminations on
the remote control unit
do not light.
